SALTEK
Inventarna številka:A04196
DL-Cat.6A-M
DL-Cat.6A-M
Price on request
Dostava se obračuna ob zaključku nakupa.
SALTEK DL-Cat.6A-M — LPZ 1 and higher, Ethernet without PoE, fine SPD for Ethernet networks Cat.5e, LPZ 1 to LPZ 2 boundary installation close to protected device, for networks without PoE, module for installation into DL-PL-RACK-1U box, DL-...-M = SPD output on front panel, DL-...-R-M = SPD output on rear panel.
Technical specifications
| SALTEK order number | A04196 |
|---|---|
| EAN | 8595090541967 |
| Nominal voltage | 8.5 V |
| Maximum operating voltage (DC) | 8.5 V DC |
| Nominal load current | 0.5 A |
| Frequency / bandwidth value | 500 MHz |
| ETIM class | EC000943 |
| Net weight | 27 g |
| Packing dimensions | 26 × 98 × 42.5 mm |
