Relpol
Inventarna številka:RSR58-60D75
Relpol RSR58-60D75 – Solid State Relays
Relpol RSR58-60D75 – Solid State Relays
Price on request
Dostava se obračuna ob zaključku nakupa.
Two-channel solid-state relay – zero-cross switching. Rated load: 50 A / 600 V AC. Control input: 4–32 V DC. Output voltage: 24–660 V AC. Load current: 50 A. IP20. Blocking voltage: 1200 Vpk.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Mounting | With screw terminals |
| Depth | 45,7 |
| Width mm | 58,4 |
| Height mm | 46 |
| Weight kg | 0,185 |
| ETIM class | EC002055 |
| Relay type | RSR58 |
| Ip cover | IP 20 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
