Relpol
SKU:RSR54-60D100
Relpol RSR54-60D100 – Solid State Relays
Relpol RSR54-60D100 – Solid State Relays
Price on request
Shipping calculated at checkout.
Single-phase relays, zero-cross switching, with TVS protection. Control input: 3–32 V DC. Rated load AC1: 100 A / 600 V AC. Load current: 100 A, output voltage: 24–660 V AC, IP20.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Mounting | With screw terminals |
| Depth | 45,7 |
| Width mm | 58,6 |
| Height mm | 29,4 |
| Weight kg | 0,08 |
| ETIM class | EC002055 |
| Relay type | RSR54 |
| Ip cover | IP 20 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
