Relpol
SKU:RM85-3021-25-1024
Relpol RM85-3021-25-1024 – Industrial Relays
Relpol RM85-3021-25-1024 – Industrial Relays
Price on request
Shipping calculated at checkout.
Miniature relays RM85-3021-25-1024, 1 NO. Contact material: AgSnO2. Voltage coil 24 V DC. Rated load AC1 16 A / 250 V AC. Mounting: for PCB and sockets. Cover protection category IP 40.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 24 V |
| Contact material | AgSnO2 |
| Number and type of contacts | 1 NO |
| Rated load AC1 | 16 A / 250 V AC |
| Rated load AC3 | 0,5 kW |
| Rated load DC1 | 16 A / 24 V DC |
| Rated switching voltage | 250 V AC |
| Mounting | for PCB and sockets |
| Depth | 29 |
| Width mm | 12,7 |
| Height mm | 15,7 |
| Weight kg | 0,014 |
| ETIM class | EC001437 |
| Relay type | RM85 |
| Ip cover | IP 40 |
