Relpol RM18A-3021-35-S024 – Industrial Relays

Name: Relpol RM18A-3021-35-S024 – Industrial Relays
Brand: Relpol
SKU: RM18A-3021-35-S024
Availability: InStock

Price on request

Razprodano

Dostava se obračuna ob zaključku nakupa.

Request a price

Miniature electromagnetic relay for PCB mounting. Height: 15.5 mm. Contact configuration: 1Z – 1 NO contact; AC1 - 5 A / 250 V; Rated coil voltage (Un): 24 V DC; sensitive coil. Dimensions: 18,2 x 10,2 x 15,5 mm. IP 67. Contact material: AgSnO2.

Technical specifications

Type of coil supply	DC sensitive coil
Coil voltage	24 V
Contact material	AgSnO2
Number and type of contacts	1 NO
Rated load AC1	5 A / 250 V AC
Rated switching voltage	250 V AC
Mounting	for PCB
Depth	18,2
Width mm	10,2
Height mm	15,5
Weight kg	0,0057
ETIM class	EC001437
Relay type	Miniature relays
Ip cover	IP 67
