Relpol
Inventarna številka:R2M-2012-23-1024
Relpol R2M-2012-23-1024 – Industrial Relays
Relpol R2M-2012-23-1024 – Industrial Relays
Price on request
Dostava se obračuna ob zaključku nakupa.
Industrial relays R2M-2012-23-1024, 2 CO. Contact material: AgNi. Voltage coil 24 V DC. Rated load AC1 5 A / 250 V AC. Mounting: for plug-in sockets. Cover protection category IP 40.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 24 V |
| Contact material | AgNi |
| Number and type of contacts | 2 CO |
| Rated load AC1 | 5 A / 250 V AC |
| Rated load DC1 | 5 A / 24 V DC |
| Rated switching voltage | 250 V AC |
| Mounting | for plug-in sockets |
| Depth | 27,5 |
| Width mm | 14 |
| Height mm | 32,9 |
| Weight kg | 0,022 |
| ETIM class | EC001437 |
| Execution | Standard |
| Relay type | R2M |
| Ip cover | IP 40 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
