Relpol
Inventarna številka:PRUCT-M-2052-26-W024-V0
Relpol PRUCT-M-2052-26-W024-V0 – Interface Relays
Relpol PRUCT-M-2052-26-W024-V0 – Interface Relays
Price on request
Dostava se obračuna ob zaključku nakupa.
Relays for railroad industry - interface PRUCT-M-2052-26-W024-V0, 2 NO contact gap ≥ 2,5 mm. Contact material: AgNi. Voltage coil 24 V DC. Rated load AC1 16 A / 250 V AC. Mounting: mounting on 35 mm rail. Cover protection category IP 00.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 24 V |
| Contact material | AgNi |
| Number and type of contacts | 2 NO contact gap ≥ 2,5 mm |
| Rated load AC1 | 16 A / 250 V AC |
| Rated load DC1 | 16 A / 24 V DC |
| Rated switching voltage | 250 V AC |
| Mounting | mounting on 35 mm rail |
| Depth | 84,5 |
| Width mm | 41,5 |
| Height mm | 77,3 |
| Weight kg | 0,154 |
| ETIM class | EC001437 |
| Relay type | PRUCT-M |
| Ip cover | IP 00 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
