Relpol
SKU:PIR6W-1PS-36VDC-O
Relpol PIR6W-1PS-36VDC-O – Interface Relays
Relpol PIR6W-1PS-36VDC-O – Interface Relays
Price on request
Shipping calculated at checkout.
Interface relays PIR6W-1PS-36VDC-O, 1 NO, transistor output. Contact material: . Voltage coil 36 V DC. Rated load AC1 . Mounting: mounting on 35 mm rail. Cover protection category IP 20.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 36 V |
| Number and type of contacts | 1 NO |
| Rated load DC1 | 2 A/ 24 V DC |
| Rated switching voltage | 24 V DC |
| Mounting | mounting on 35 mm rail |
| Depth | 98,5 |
| Width mm | 6,2 |
| Height mm | 85,5 |
| Weight kg | 0,045 |
| ETIM class | EC001437 |
| Relay type | PIR6W-1PS |
| Ip cover | IP 20 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
