Relpol
SKU:PIR6W-1P-24VAC/DC
Relpol PIR6W-1P-24VAC/DC – Interface Relays
Relpol PIR6W-1P-24VAC/DC – Interface Relays
Price on request
Shipping calculated at checkout.
Interface relay, Output:1C/O, Supply: 24VAC/DC, Rated load: 6A, width: 6,2mm
Technical specifications
| Type of coil supply | AC/DC |
|---|---|
| Coil voltage | 24 V |
| Contact material | AgSnO2 |
| Number and type of contacts | 1 CO |
| Rated load AC1 | 6 A / 250 V AC |
| Rated load DC1 | 6 A / 24 V DC |
| Mounting | mounting on 35 mm rail |
| Depth | 98,5 |
| Width mm | 6,2 |
| Height mm | 85,5 |
| ETIM class | EC001437 |
| Relay type | PIR6W-1P |
| Ip cover | IP 20 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
