Relpol
Inventarna številka:PI85-024AC-00LV
Relpol PI85-024AC-00LV – Interface Relays
Relpol PI85-024AC-00LV – Interface Relays
Price on request
Dostava se obračuna ob zaključku nakupa.
Relpol PI85-024AC-00LV. Interface Relays.
Technical specifications
| Type of coil supply | AC |
|---|---|
| Coil voltage | 24 V |
| Contact material | AgNi |
| Number and type of contacts | 1 CO |
| Rated load AC1 | 16 A / 250 V AC |
| Rated load AC3 | 0,5 kW |
| Rated load DC1 | 16 A / 24 V DC |
| Rated switching voltage | 250 V AC |
| Connection | 35 mm DIN rail mounting |
| Depth (mm) | 81,6 |
| Width (mm) | 15,9 |
| Height (mm) | 67 |
| Weight (kg) | 0,06 |
| ETIM class | EC001437 |
| Relay type | PI85 |
| Enclosure protection | IP 20 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
