Relpol PI6-1P-230VAC/DC – Interface Relays

Name: Relpol PI6-1P-230VAC/DC – Interface Relays
Brand: Relpol
SKU: PI6-1P-230VAC/DC
Availability: InStock

Price on request

Razprodano

Dostava se obračuna ob zaključku nakupa.

Request a price

Interface relays PI6-1P-230VAC/DC (gray), 1 CO. Contact material: AgSnO2. Voltage coil 230 V AC/DC. Rated load AC1 6 A / 250 V AC. Mounting: mounting on 35 mm rail. Cover protection category IP 20.

Technical specifications

Type of coil supply	AC/DC
Coil voltage	230 V
Contact material	AgSnO2
Number and type of contacts	1 CO
Rated load AC1	6 A / 250 V AC
Rated load DC1	6 A / 30 V DC
Mounting	mounting on 35 mm rail
Depth	93,8
Width mm	6,2
Height mm	80
Weight kg	0,04
ETIM class	EC001437
Relay type	PI6-1P
Ip cover	IP 20
