Pizzato
Inventarna številka:FD 2253-E11M2V9
FD 2253-E11M2V9
FD 2253-E11M2V9
Availability: Ships in 2–3 weeks
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
Position switch with porcelain roller lever, Housing: Metal housing, one threaded M20x1,5 conduit entry (FD series), Contact block: 2NO+1NC slow action (B22), Head: For rotating levers with porcelain roller, Actuator: With porcelain roller lever, 9 mm diameter, Protection degree: IP67 according to EN 60529, Positive opening: Yes.
Technical specifications
| Manufacturer part number | FD 2253-E11M2V9 |
|---|---|
| EAN | 8018851329180 |
| Minimum order quantity | 1 |
| Weight | 0 g |
| Customs tariff number | 85369095 |
| Product range | FD |
| ETIM class | EC000030 |
Documentation
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
