Relpol
SKU:PIR6WB-1PS-12VDC-C
Relpol PIR6WB-1PS-12VDC-C – Interface Relays
Relpol PIR6WB-1PS-12VDC-C – Interface Relays
Price on request
Shipping calculated at checkout.
Interface relays PIR6WB-1PS-12VDC-C, 1 NO, transistor output. Voltage coil 12 V DC. Mounting: mounting on 35 mm rail. Cover protection category IP 20.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 12 V |
| Number and type of contacts | 1 NO |
| Rated load DC1 | 1 A/ 48 V DC |
| Rated switching voltage | 48 V DC |
| Mounting | mounting on 35 mm rail |
| Depth | 98,3 |
| Width mm | 6,2 |
| Height mm | 84,6 |
| Weight kg | 0,055 |
| ETIM class | EC001437 |
| Execution | niestandardowe |
| Relay type | PIR6WB-1PS |
| Ip cover | IP 20 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
