Pizzato
SKU:FM 753-E0V9
FM 753-E0V9
FM 753-E0V9
Regular price
€20,55 EUR
Regular price
Sale price
€20,55 EUR
Shipping calculated at checkout.
Availability: Ships in 2–3 weeks
Quantity
Couldn't load pickup availability
Position switch with porcelain roller lever, Housing: Metal housing, one threaded PG 13,5 conduit entry (FM series), Contact block: 1NO+1NC slow action, overlapped contacts (B7), Head: For rotating levers with porcelain roller, Actuator: With porcelain roller lever, 9 mm diameter, Protection degree: IP67 according to EN 60529, Positive opening: Yes.
Technical specifications
| Manufacturer part number | FM 753-E0V9 |
|---|---|
| EAN | 8018851102363 |
| Minimum order quantity | 1 |
| Weight | 249 g |
| Customs tariff number | 85369095 |
| Product range | FM |
| ETIM class | EC000030 |
Documentation
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Pizzato Elettrica
