SALTEK
SKU:A07120
DL-VDSL3
DL-VDSL3
Price on request
Spese di spedizione calcolate al check-out.
SALTEK DL-VDSL3 — Combination of coarse and fine protection, for protection of one pair of high-speed analogue line in telecommunication equipment (e.g. VDSL2), the scope of delivery: universal plastic adapter for mounting on DIN rail and GND 2 holder.
Technical specifications
| SALTEK order number | A07120 |
|---|---|
| EAN | 8595090571209 |
| Nominal voltage | 60 V |
| Maximum operating voltage (DC) | 60 V DC |
| Nominal load current | 0.6 A |
| Frequency / bandwidth value | 300 MHz |
| ETIM class | EC000943 |
| Net weight | 60 g |
| Packing dimensions | 95 × 70 × 40 mm |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
SALTEK
