Relpol
SKU:RG25-3022-28-1012
Relpol RG25-3022-28-1012 – Industrial Relays
Relpol RG25-3022-28-1012 – Industrial Relays
Price on request
Spese di spedizione calcolate al check-out.
Industrial relays RG25-3022-28-1012, 2 NO. Contact material: AgSnO2. Voltage coil 12 V DC. Rated load AC1 25 A / 400 V AC. Mounting: mounting on 35 mm rail. Cover protection category IP 20.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 12 V |
| Contact material | AgSnO2 |
| Number and type of contacts | 2 NO |
| Rated load AC1 | 25 A / 400 V AC |
| Rated load DC1 | 25 A / 24 V DC |
| Rated switching voltage | 400 V AC |
| Mounting | mounting on 35 mm rail |
| Depth | 26 |
| Width mm | 53,7 |
| Height mm | 75,5 |
| Weight kg | 0,13 |
| ETIM class | EC001437 |
| Relay type | RG25 |
| Ip cover | IP 20 |
| Time ranges | 0,13 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
