SALTEK
Inventarna šifra proizvoda (SKU):A04134
HX 090-SMA F/M
HX 090-SMA F/M
Price on request
Poštarina se obračunava prilikom završetka kupnje.
SALTEK HX 090-SMA F/M — SMA connectors, 50 Ohm, lightning current arrester for coaxial line, installation at the boundary of LPZ 0 and LPZ 1 zones at the line entry into building, for protection of telecommunication equipment against impact of direct or indirect lightning strike, suitable for the combined signal and power supply distribution.
Technical specifications
| SALTEK order number | A04134 |
|---|---|
| EAN | 8595090541349 |
| Nominal voltage | 70 V |
| Maximum operating voltage (DC) | 70 V DC |
| Nominal load current | 6 A |
| Frequency / bandwidth value | 3800 MHz |
| ETIM class | EC000943 |
| Net weight | 135 g |
| Packing dimensions | 40 × 95 × 70 mm |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
SALTEK
