Relpol RM84-2012-35-5115 – Industrial Relays

Name: Relpol RM84-2012-35-5115 – Industrial Relays
Brand: Relpol
SKU: RM84-2012-35-5115
Availability: InStock

Price on request

Wyprzedane

Koszt wysyłki obliczony przy realizacji zakupu.

Request a price

Miniature relays RM84-2012-35-5115, 2 CO. Contact material: AgNi. Voltage coil 115 V AC. Rated load AC1 8 A / 250 V AC. Mounting: for PCB and sockets. Cover protection category IP 67.

Technical specifications

Type of coil supply	AC
Coil voltage	115 V
Contact material	AgNi
Number and type of contacts	2 CO
Rated load AC1	8 A / 250 V AC
Rated load AC3	0,37 kW
Rated load DC1	8 A / 24 V DC
Rated switching voltage	250 V AC
Mounting	for PCB and sockets
Depth	29
Width mm	12,7
Height mm	15,7
Weight kg	0,014
ETIM class	EC001437
Relay type	RM84
Ip cover	IP 67
