Relpol PIR6W-1PS-24VAC/DC-C – Interface Relays
Relpol PIR6W-1PS-24VAC/DC-C – Interface Relays
Price on request
Spese di spedizione calcolate al check-out.
Interface relays PIR6W-1PS-24VAC/DC-C, 1 NO, transistor output. Contact material: . Voltage coil 24 V AC/DC. Mounting: mounting on 35 mm rail. Cover protection category IP 20.
Technical specifications
| Type of coil supply | AC/DC |
|---|---|
| Coil voltage | 24 V |
| Number and type of contacts | 1 NO |
| Rated load DC1 | 1 A/ 48 V DC |
| Rated switching voltage | 48 V DC |
| Mounting | mounting on 35 mm rail |
| Depth | 98,5 |
| Width mm | 6,2 |
| Height mm | 85,5 |
| Weight kg | 0,045 |
| ETIM class | EC001437 |
| Relay type | PI6RW-1PS |
| Ip cover | IP 20 |
