Relpol PI85-024AC-M91G-TS-2011 – Interface Relays
Relpol PI85-024AC-M91G-TS-2011 – Interface Relays
Price on request
Spese di spedizione calcolate al check-out.
Interface relays PI85-024AC-M91G-TS-2011, 1 CO. Contact material: AgNi. Voltage coil 24 V AC. Rated load AC1 16 A / 250 V AC. Mounting: mounting on 35 mm rail. Cover protection category IP 20.
Technical specifications
| Type of coil supply | AC |
|---|---|
| Coil voltage | 24 V |
| Contact material | AgNi |
| Number and type of contacts | 1 CO |
| Rated load AC1 | 16 A / 250 V AC |
| Rated load AC3 | 0,5 kW |
| Rated load DC1 | 16 A / 24 V DC |
| Rated switching voltage | 250 V AC |
| Mounting | mounting on 35 mm rail |
| Depth | 80 |
| Width mm | 15,6 |
| Height mm | 67 |
| Weight kg | 0,061 |
| ETIM class | EC001437 |
| Relay type | PI85 |
| Ip cover | IP 20 |
