Relpol
SKU:PIR6W-1PS-12VDC-R (SZARE) (CE)
Relpol PIR6W-1PS-12VDC-R (SZARE) (CE) – Solid State Relays
Relpol PIR6W-1PS-12VDC-R (SZARE) (CE) – Solid State Relays
Price on request
Versand wird beim Checkout berechnet
Relpol PIR6W-1PS-12VDC-R (SZARE) (CE). Solid State Relays.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 12 V |
| Contact material | AgSnO2 |
| Number and type of contacts | 1 CO |
| Rated load AC1 | 6 A / 250 V AC |
| Rated load DC1 | 6 A / 24 V DC |
| Rated switching voltage | 250 V AC |
| Connection | 35 mm DIN rail mounting |
| Depth (mm) | 98,5 |
| Width (mm) | 6,2 |
| Height (mm) | 85,5 |
| Weight (kg) | 0,045 |
| ETIM class | EC001437 |
| Relay type | PIR6W-1PS |
| Enclosure protection | IP 20 |
Technical documentation
Access the latest datasheets, certificates, manuals, CAD files and detailed technical information directly from the manufacturer.
Manufacturer:
Relpol
