Relpol
SKU:PI6-1P-24VDC
Relpol PI6-1P-24VDC – Interface Relays
Relpol PI6-1P-24VDC – Interface Relays
Price on request
Versand wird beim Checkout berechnet
Interface relays PI6-1P-24VDC (gray), 1 CO contact output. Contact material: AgSnO2. Voltage coil 24 V DC. Rated load AC1 6 A / 250 V AC. Mounting: mounting on 35 mm rail. Cover protection category IP 20.
Technical specifications
| Type of coil supply | DC |
|---|---|
| Coil voltage | 24 V |
| Contact material | AgSnO2 |
| Number and type of contacts | 1 CO |
| Rated load AC1 | 6 A / 250 V AC |
| Rated load DC1 | 6 A / 30 V DC |
| Mounting | mounting on 35 mm rail |
| Depth | 93,8 |
| Width mm | 6,2 |
| Height mm | 80 |
| Weight kg | 0,04 |
| ETIM class | EC001437 |
| Relay type | PI6-1P |
| Ip cover | IP 20 |
